Shop Gen 1 to Gen 3 Coyote Oil Pump Gears and Coyote Oil Pump Upgrade Kits
All Coyote Oil Pump Gears and Sprockets
If you're chasing power on a Coyote 5.0L, whether it's with a blower, turbo, nitrous, big cams, or just a higher rev limit - the factory oil pump is the part most likely to end your engine.
Shop our high-performance billet oil pump gears below for Ford Coyote engines - for both Mustang and F-150 applications. We carry gears rated up to and past 9,000 RPM and 2,000+ wheel horsepower.
Coyote F-150 vs Mustang Oil Pump Gear Width Table
| Application | Years | Gear Width | Correct Boundary Gear Set |
|---|---|---|---|
| Mustang GT 5.0L | 2011–2026 | .560" | CM-OPG-Mustang |
| Mustang Shelby GT350 5.2L | 2015–2020 | .560" | CM-OPG-Mustang |
| F-150 5.0L | 2011–2014 | .510" (small) | CM-OPG-F150 |
| F-150 5.0L | 2015–2017 | .560" | CM-OPG-Mustang |
| F-150 5.0L | 2018–2020 | .510" (small) | CM-OPG-F150 |
Coyote Oil Pump Gear Frequently asked Questions
If you're chasing power on a Coyote 5.0L, whether a blower, turbo, nitrous, big cams, or just a higher rev limit - the factory oil pump is the part most likely to end your engine. This guide explains why, what to look for, and how to fix it correctly for your platform.
The Problem: Factory Powder-Metal Oil Pump Gears
Ford builds the Coyote oil pump gears (and the crank timing sprocket that drives them) out of sintered powdered metal. That works fine for a 412–460 hp factory tune. It does not work once you push the engine past its design envelope.
The factory gears are brittle. Under sustained high RPM, harmonic spikes from forced induction, or aggressive rev limits, they fracture. When a gear cracks, the pump stops moving oil. You lose pressure in a heartbeat — bearings spin, the bottom end lets go, and what started as a $200 part becomes a $15,000 short block.
Failure thresholds the Coyote community sees repeatedly:
- Sustained RPM above ~7,000 (especially with the rev limiter raised)
- Any forced induction — supercharger, turbo, centrifugal
- Nitrous use
- Track and road-course duty cycles
- High-mileage trucks pulling heavy loads
Catastrophic failure is often the first warning. By the time the oil light flickers, the engine is usually already damaged.
Warning Signs of Oil Pump Failure in Coyote 5.0L
- Low oil pressure at idle (especially hot idle)
- Oil light flicker under load or during hard acceleration
- VCT phaser rattle on startup or at low RPM
- Engine knock, lifter tick, or top-end noise
- Metal in the oil filter on cut-open
If you see any of these, stop driving and inspect. More commonly, owners catch the problem on a pre-emptive teardown — which is exactly the right time to upgrade.
NO - The Coyote oil pump is not a one-size-fits-all part. The F-150 uses a smaller gear and housing than the Mustang for part of its production run.
Mustang gears do not fit 2011–2014 or 2018+ F-150 pumps. The 2015–2017 F-150 is the only truck year range that shares the Mustang gear set. Get this wrong and the parts physically will not assemble.
If you're unsure which generation you have:
Gen 1 = 2011–2014 Mustang / 2011–2014 F-150
Gen 2 = 2015–2017 Mustang / 2015–2017 F-150
Gen 3 = 2018–2023 Mustang / 2018–2020 F-150
You should. While you don't HAVE to replace the crankshaft timing sprocket, it's not a good idea to leave it OEM on a boosted Coyote.
The crankshaft timing sprocket drives the oil pump gears. It's also powder metal from the factory, and it's a documented weak link under boost and high RPM. If you upgrade the pump gears but leave the OEM sprocket in place, you've moved the failure point one link up the chain. Best practice on any serious build is to replace the sprocket at the same time — the labor is already done with the front cover off.
YES! We have pre-matched bundles stocked on our site, and are happy to help match sprocekts for your generation and Coyote platform.
The right combination depends on how the engine is being used.
Bolt-On / Tune-Only Mustang (NA, stock rev limit)
Gears only is enough if you're not raising the limiter or adding boost. CM-OPG-Mustang is the minimum insurance policy.
Boosted Mustang or Track Car Oil Pump Kit (supercharger, turbo, raised rev limit)
Assembled pump plus crank sprocket. The sprocket failure mode shows up under the same conditions as gear failure, and you do not want to pull the front cover twice.
- Gen 1/Gen 2 (2011–2017): CM-S1 + CM-SP-11 or CM-SP-15 (match year)
- Gen 3 (2018–2023): CM-S1-R2 + CM-SP-15 or CM-SP-15-GRIP
F-150 Tow Rig or High-Mile Truck
Trucks live at high oil temps under sustained load. Same answer as the boosted Mustang — assembled pump plus sprocket, matched to the correct gear width.
- 2011–2014 F-150: CM-OPG-F150 (gears only, since no F-150-specific assembled pump exists in this housing) + CM-SP-11
- 2015–2017 F-150: CM-S1 + CM-SP-15
- 2018–2020 F-150: CM-OPG-F150 + CM-SP-15
Full Send Build (1,000+ hp target, road course, drag)
Assembled pump, grip-surface crank sprocket, and budget for a fresh OEM timing chain and tensioners while you're in there. This is the last time you want to touch the front of this engine for a long time.
- CM-S1-R2 (or R3) + CM-SP-15-GRIP
